Klasa F900E600 ClassD400 ClassC250 classB125 Class
C250 classCANAL C250  - 1
Powrót do wyników

CANAL C250

Hinged channel grating with hinge and closing system

Articulación

Material

Casting manufactured in spheroidal-graphite cast iron (ductile cast iron) in accordance with the EN-1563 Standard.

Features

Grating for modular mounting for perpendicular installation at the kerb or crossing of the intercepting road. Easy opening for gutter cleaning operations. Anti-slip surface. With closing system on one side and articulation on the other side.

Coating

Epoxy-polyester with a thickness of 100 microns, free of solvents compliant with the standard 199/13/CEE, black RAL-9004.

ModelWymiary wpustu (a) mmWysokość wpustu (h) mmAbsorpcja powierzchniowa dm3CertyfikatyInformacje techniczne
7127 778x195257AFNOR
7128 750x3003011,60AFNOR
7129 750x3953017,00AFNOR
7130 750x5003519AFNOR
Poproś o konsultację. Nasz dział inżynieryjny przeanalizuje Twój projekt
zaproponować najlepsze rozwiązanie. Zadzwońpod numer +34 938 034 697
